Tradeboard on Raspberry Pi: Setup Guide ​

This guide helps you install and configure Tradeboard on Raspberry Pi models 3, 4, or 5 (4GB+ RAM), preferably running Ubuntu 24.04+ server edition.

Hardware & OS Recommendations ​

  • Raspberry Pi Model: 3, 4, or 5 (minimum 4GB RAM)
  • SD Card: Recommended 128GB; minimum 64GB
  • Operating System: Ubuntu 24.04+ Server edition (preferred)
  • RPi official power adapter: Recommended to buy for stable power supply and avoid RPi abrupt shutdowns and restarts. Get Ubuntu images for Raspberry Pi

Initial System Preparation ​

1. Flash OS to SD Card ​

  • Use Raspberry Pi Imager to prepare your SD card.
  • Configure initial user, password, Wi-Fi details, etc.

2. First Boot & Access ​

  • Insert SD card, power on Raspberry Pi.

  • Connect HDMI to monitor/TV and USB keyboard or get the private IP from your router/AP and SSH to RPi instance :

    ssh <username>@<raspberry-pi-ip>

  • Official Raspberry Pi SSH guide

3. Setup Swap ​

  • Recommend swap size: max 4GB, min 2GB

    sudo fallocate -l 4G /swapfile
sudo chmod 600 /swapfile
sudo mkswap /swapfile
sudo swapon /swapfile
echo '/swapfile none swap sw 0 0' | sudo tee -a /etc/fstab

Tradeboard Installation ​

Option 1: Using Official Install Script ​

  • Visit: Install Instructions
  • Follow the script prompts.
    (Typically involves downloading, running the script, and entering your details.)

1. Install Docker (Ubuntu/ARM)

Docker Ubuntu install guide

sudo apt-get update
sudo apt-get install ca-certificates curl gnupg
curl -fsSL https://get.docker.com -o get-docker.sh
sudo sh get-docker.sh

2. Install Docker Buildx for ARM

docker buildx version

If not present, follow: https://docs.docker.com/buildx/working-with-buildx/#install-buildx

3. Get nginx Docker Image (reverse proxy)

docker pull nginx:latest

4. Clone the Tradeboard Repo

git clone https://github.com/wesoftcorp/tradeboard-docs
cd tradeboard

5. Build Tradeboard Docker Image

docker build -t tradeboard:latest .

6. Configure Environment

  • Copy .sample.env as .env and fill in broker API key, secret, and client ID

    cp .sample.env .env
vi .env

7. Use docker-compose.yaml

  • Edit/verify docker-compose.yaml inside /tradeboard

  • If you have built the docker image in the previous step, you can comment the build: block and its nested keys (using #) in docker-compose.yaml.

  • Launch services:

    docker compose up -d

    Use the docker compose subcommand (Compose v2). The standalone docker-compose v1 binary is end of life and is not installed by the get-docker.sh script above.

8. Configure Nginx Reverse Proxy

  • Reference: Install Multi-Script Example

  • Typical location blocks for nginx. Tradeboard publishes two ports, so you need both: the Flask app on 5000 and the WebSocket proxy on 8765. Without the /ws block the dashboard loads but live prices never update.

    location = /ws {
    proxy_pass http://127.0.0.1:8765;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
    proxy_set_header Host $host;
    proxy_read_timeout 86400s;
    proxy_send_timeout 86400s;
    proxy_buffering off;
}

location /ws/ {
    proxy_pass http://127.0.0.1:8765/;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
    proxy_set_header Host $host;
    proxy_read_timeout 86400s;
    proxy_send_timeout 86400s;
    proxy_buffering off;
}

location /socket.io/ {
    proxy_pass http://127.0.0.1:5000/socket.io/;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
    proxy_set_header Host $host;
}

location / {
    proxy_pass http://127.0.0.1:5000;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    proxy_set_header X-Forwarded-Proto $scheme;
}

  • Do not add Upgrade / Connection "upgrade" headers to the location / { block. Doing so sends every ordinary request upstream with a bogus upgrade header, which breaks HTTP/1.1 keep-alive to Gunicorn and shows up as intermittent failures. Only the /ws, /ws/ and /socket.io/ blocks need them.

  • Then set the matching values in .env so the browser is told the right address, and so Tradeboard trusts the forwarded client IP:

    dotenv
    HOST_SERVER = 'https://yourdomain.com'
WEBSOCKET_URL='wss://yourdomain.com/ws'
WEBSOCKET_HOST='0.0.0.0'
TRUST_PROXY_HEADERS = 'TRUE'

    Leave ZMQ_HOST on 127.0.0.1. It is the unauthenticated internal tick bus and must never be reachable off the host.

  • Adapt your domain/server settings accordingly.

I prefer to separate out the runtime files and folders from the github cloned folder and keep them separate. So if you build the docker image as in above step #5, you can very well take the docker-compose.yaml in a separate working folder structure and have your own versions of .env file.

  • Create and mount volumes under /work for logs, keys, strategies, etc.

    /work
  /storage
     /tradeboard
         docker-compose.yaml
         .env
         applogs/
         logs/
         keys/
         strategies/
         db/

  • Update docker-compose.yaml example. The application lives at /app inside the container, so the container-side path of every bind mount must start with /app:

    volumes:
  - /work/storage/tradeboard/db:/app/db
  - /work/storage/tradeboard/log:/app/log
  - /work/storage/tradeboard/keys:/app/keys
  - /work/storage/tradeboard/strategies:/app/strategies
  - /work/storage/tradeboard/tmp:/app/tmp
  - /work/storage/tradeboard/.env:/app/.env

    Mounting to /tradeboard/... writes to a directory the application never reads, so nothing persists. The shipped docker-compose.yaml uses named volumes for these same five paths; replace them with bind mounts only if you want the files visible on the host filesystem.

WARNING

The container runs as UID/GID 1000. Give the host directories and the .env file that ownership, or the first-run secret rotation cannot write and the worker restarts in a loop:

sudo chown -R 1000:1000 /work/storage/tradeboard
sudo chmod 600 /work/storage/tradeboard/.env

Securing your setup ​

A. Basic Server Protection (iptables, fail2ban) ​

1. Install iptables

sudo apt-get update
sudo apt-get install iptables

  • Example: Allow SSH and HTTP(S), block others:

    sudo iptables -A INPUT -p tcp --dport 22 -j ACCEPT
sudo iptables -A INPUT -p tcp --dport 80 -j ACCEPT
sudo iptables -A INPUT -p tcp --dport 443 -j ACCEPT
sudo iptables -A INPUT -m conntrack --ctstate ESTABLISHED,RELATED -j ACCEPT
sudo iptables -A INPUT -j DROP
sudo iptables-save | sudo tee /etc/iptables/rules.v4

  • iptables guide

2. Install fail2ban

sudo apt-get install fail2ban

  • Enable default jails for SSH, edit /etc/fail2ban/jail.local for customization.

  • Start and enable service:

    sudo systemctl enable fail2ban
sudo systemctl start fail2ban

  • fail2ban documentation

  • Example setup

B. Using Cloudflare for Reverse Proxy & Security ​

  • Register at Cloudflare.
  • Add Your Domain:
    • Point your domain's DNS to Cloudflare's nameservers.
    • Set up proxy status for your domain so Cloudflare sits between users and your Pi.
  • HTTPS and SSL:
    • Use Cloudflare’s “Flexible SSL” or, for end-to-end encryption, generate origin certificates on Cloudflare and install them behind Nginx.
  • Firewall Rules & Monitoring:
  • Analytics & DDoS Protection:
    • Monitor connection health and traffic patterns through Cloudflare Analytics.
  • Cloudflare Nginx integration guide

Useful References ​

Tradeboard is now ready on your Raspberry Pi! Start building and deploying your trading strategies.
