Setting Up HTTPS for Tradeboard on Windows with Caddy ​

Run Tradeboard locally on https://tradeboard.local with a valid SSL certificate, no browser warnings, and zero changes to app.py.

Why this setup? ​

OAuth flows for brokers like shoonya,hdfcsky often require HTTPS redirect URLs. Running Tradeboard on plain http://127.0.0.1:5000 works for testing, but production-like local development needs:

  • A proper hostname (tradeboard.local instead of 127.0.0.1)
  • HTTPS with a trusted certificate (no Not Secure warnings)
  • No code changes to Tradeboard itself

Caddy handles all of this in front of your Flask app as a reverse proxy.

Prerequisites ​

  • Windows 10 or 11
  • Tradeboard already cloned and running locally
  • Administrator access for two one-time setup steps (hosts file edit, certificate trust)

Step 1: Download Caddy ​

Go to https://caddyserver.com/download

Select:

  • Platform: Windows
  • Architecture: amd64

Click Download. You'll get a file named something like caddy_windows_amd64_custom.exe.

Step 2: Place and rename the binary ​

Create a folder to hold Caddy:

powershell
mkdir C:\caddy

Move the downloaded file into C:\caddy\ and rename it to caddy.exe.

In PowerShell:

powershell
cd C:\caddy
Rename-Item caddy_windows_amd64.exe caddy.exe

Verify it works:

powershell
.\caddy.exe version

You should see something like:

v2.11.2 h1:iOlpsSiSKqEW+SIXrcZsZ/NO74SzB/ycqqvAIEfIm64=

Tip: Show file extensions in Windows ​

If you see caddy.exe.exe after renaming, Windows is hiding extensions. Open File Explorer, click View > Show > File name extensions, then rename again.

Step 3: Edit the hosts file ​

This maps tradeboard.local to your local machine.

  1. Press the Windows key, type Notepad
  2. Right-click Notepad and select Run as administrator
  3. In Notepad: File > Open
  4. Navigate to: C:\Windows\System32\drivers\etc\
  5. Change the file type dropdown (bottom right) from Text Documents (*.txt) to All Files
  6. Open hosts

Add this line:

127.0.0.1    tradeboard.local

A typical hosts file will look like this after editing:

# localhost name resolution is handled within DNS itself.
#	127.0.0.1       localhost
#	::1             localhost

# Added by Docker Desktop
192.168.1.6 host.docker.internal
192.168.1.6 gateway.docker.internal

# To allow the same kube context to work on the host and the container:
127.0.0.1 kubernetes.docker.internal
127.0.0.1 tradeboard.local
# End of section

Save and close.

Verify the entry works:

powershell
ping tradeboard.local

You should see replies from 127.0.0.1. If you see could not find host, the hosts file did not save correctly. Reopen Notepad as Administrator and try again.

Step 4: Create the Caddyfile ​

Tradeboard ships with a default Caddyfile in the project root. If yours is missing, create it.

Navigate to your Tradeboard project folder:

powershell
cd D:\tradeboard-remote\tradeboard
notepad Caddyfile

When Notepad asks if you want to create the file, click Yes. Paste this:

tradeboard.local {
    reverse_proxy localhost:5000
}

Save and close.

Note on the Caddyfile name ​

The file must be named exactly Caddyfile with no extension. If Notepad saves it as Caddyfile.txt, rename it:

powershell
Rename-Item Caddyfile.txt Caddyfile

Step 5: Run Caddy for the first time (Administrator) ​

The first run installs Caddy's local certificate authority into Windows so browsers trust the auto-generated SSL certificate.

  1. Press Windows key, type PowerShell
  2. Right-click Windows PowerShell and select Run as administrator
  3. Run these commands:
powershell
cd D:\tradeboard-remote\tradeboard
C:\caddy\caddy.exe run

Windows will show a security dialog asking permission to install a root certificate. Click Yes.

You should see logs like:

INFO    using adjacent Caddyfile
INFO    adapted config to JSON
INFO    http.auto_https enabling automatic HTTP->HTTPS redirects
INFO    serving initial configuration

Leave this terminal open. Caddy is now running.

Step 6: Start Tradeboard in a separate terminal ​

Open another PowerShell window (no admin needed). Navigate to the project folder and start Tradeboard:

powershell
cd D:\tradeboard-remote\tradeboard
uv run app.py

You should see:

╭─── Tradeboard v2.0.2.2 ──────────────────────────────╮
│                                                    │
│        Your Personal Algo Trading Platform         │
│                                                    │
│ Endpoints                                          │
│ Web App    http://127.0.0.1:5000                   │
│ WebSocket  ws://127.0.0.1:8765                     │
│ Docs       https://docs.algo.wesoftcorp.com                │
│                                                    │
│ Status     Ready                                   │
│                                                    │
╰────────────────────────────────────────────────────╯

Step 7: Open Tradeboard in your browser ​

Go to: https://tradeboard.local

You should see the Tradeboard login screen with a valid lock icon next to the URL. No certificate warnings.

Step 8: Update broker callback URLs ​

Now that Tradeboard runs on HTTPS, update the redirect URL in your .env file:

dotenv
REDIRECT_URL = 'https://tradeboard.local/shoonya/callback'

Match this exactly in your broker's developer console:

  • Shoonya API Portal: Edit your app and set the Redirect URL to https://tradeboard.local/shoonya/callback

Restart Tradeboard after editing .env.

All the brokers the procedure remains the same.

Daily workflow after setup ​

Once everything is set up, your daily workflow is just two terminals:

Run this from the tradeboard root folder

Terminal 1 (Caddy):

powershell
C:\caddy\caddy.exe run

Terminal 2 (Tradeboard):

powershell
uv run app.py

Press Ctrl+C in either terminal to stop. Nothing runs in the background as a service.

Optional: Single-command launcher ​

Create start.bat in your Tradeboard folder:

batch
@echo off
start "Caddy" cmd /k C:\caddy\caddy.exe run
start "Tradeboard" cmd /k uv run app.py

Double-click to launch both. Close both terminal windows when done.

Troubleshooting ​

Browser shows ERR_CONNECTION_REFUSED ​

Make sure both terminals are running. Caddy must be running for HTTPS to work, and Tradeboard must be running for Caddy to have something to proxy to.

Certificate warning in browser ​

This means Caddy's root CA is not trusted. Stop Caddy, then run as Administrator:

powershell
C:\caddy\caddy.exe trust

Accept the Windows prompt. Restart Caddy.

Port 443 already in use ​

Another service is using the HTTPS port. Common culprits:

powershell
netstat -ano | findstr :443

If IIS or World Wide Web Publishing Service is using it, stop the service. Or change Caddy to use a different port:

tradeboard.local:8443 {
    reverse_proxy localhost:5000
}

Then access Tradeboard at https://tradeboard.local:8443.

Caddy says "Caddyfile input is not formatted" ​

Cosmetic warning only. To fix, run:

powershell
C:\caddy\caddy.exe fmt --overwrite Caddyfile

Hosts file ping does not resolve ​

The most common cause is saving hosts as hosts.txt. Open C:\Windows\System32\drivers\etc\ in File Explorer with extensions visible (View > Show > File name extensions). If you see hosts.txt, delete it and edit the original hosts file again.

Removing the setup ​

If you want to undo everything:

  1. Stop Caddy and Tradeboard
  2. Untrust the Caddy CA: C:\caddy\caddy.exe untrust (as Administrator)
  3. Remove the 127.0.0.1 tradeboard.local line from C:\Windows\System32\drivers\etc\hosts
  4. Delete C:\caddy\
  5. Delete the Caddyfile from your Tradeboard folder

Summary ​

You now have Tradeboard running on https://tradeboard.local with a fully trusted SSL certificate. No background services, no code changes to Tradeboard, and OAuth callbacks work cleanly with broker APIs that require HTTPS redirect URLs.
